M60 Concrete Mix Design with OPC cement and GGBS
January 22, 2024 | by tsquarecivilengineering
Page Contents
1. Mix stipulation for the ingredients of concrete
- Grade of Concrete: M60
- Type of Cement: OPC 53 grade confirming to IS 269
- Maximum Nominal Size Aggregate: 20 mm
- Minimum Cement content: 400Kg/cum
- Maximum Water- Cement Ratio: 0.4
- Workability : 150 ± 25 mm (slump)
- Exposure Condition : Moderate for RCC
- Method of Concrete Placing : Pumping or Bucket
- Degree of Supervision : Good
- Type of Aggregate : Crushed angular Aggregate
- Chemical admixture type : Super plasticizers Confirming IS 9103:1999
2. Material Properties
- cement = 390 kg
- GGBFS =150 kg
- 20mm = 91 kg
- 12mm = 811 kg
- Crushed stone sand = 784 kg
- Chemical admixture = 3.62 kg
- Free Water = 177 kg
- Water-Cement Ratio = 0.33
- Concrete density = 2406 kg/m3
- JSW-GGBFS Confirming to IS 12089
- Specific Gravity of GGBFS: 2.91
- Chemical Admixture : FOSROC Auramix 400
- Specific Gravity of Admixture : 1.096
- JSW-GGBFS Confirming to IS 12089
- Specific Gravity
- Coarse aggregate
- 20mm : 2.66
- 12.5mm : 2.64
- Ratio of aggregate: 20mm-10% & 12.5mm-90%
- Coarse aggregate
- Fine aggregate
- Crushed stone aggregate : 2.59
- Fine aggregate
- Water: 1
- Specific Gravity
- Water Absorption
- Coarse aggregate
- 20mm : 0.29%
- 12.5mm : 0.36%
- Coarse aggregate
- Fine aggregate
- Crushed stone aggregate : 2.88%
- Fine aggregate
- Free Surface Moisture
- Fine aggregate : Nil
- Coarse aggregate: Nil
- Free Surface Moisture
- Sieve Analysis
- Coarse aggregate:
- Sieve Analysis
- Water Absorption
| IS Seive Sizes | % Passing | IS Requirement as per IS 383 Table 7 | Ratio | Combined 100% | Confirming to IS 383 table 7 | ||||||
| Single Sized | Graded | 10% | 90% | ||||||||
| 20 mm | 12.5 mm | 20 mm | 12.5 mm | 12.5 mm | 20 mm | 12.5 mm | |||||
| 20 | 91.93 | 100 | 85-100 | 100 | 100 | 9.19 | 90.00 | 99.19 | 90-100 | ||
| 12.5 | 0 | 98.78 | – | 85-100 | 90-100 | 0.00 | 88.90 | 88.90 | – | ||
| 10 | 0.44 | 52.08 | 0-20 | 0 – 45 | 40 – 85 | 0.04 | 46.87 | 46.92 | 25-55 | ||
| 4.75 | 0.2 | 0.64 | 0-5 | 0-10 | 0 – 10 | 0.02 | 0.576 | 0.60 | 0-10 | ||
| PAN | 0 | 0 | – | – | – | 0 | 0 | 0.00 | |||
- Fine Aggregate: Confirming to grading Zone II of table 4 of IS 383 Note:- as per field trials for pumpable concrete fine aggregate should pass zone II; According to IS 383 clause No. 31.2.2 allows to use crushed stone sand as fine aggregate for concrete .According to IS 383-2016 for crushed stone sand, the permeassible limit on 150 micron IS sieve is increased to20%.
| IS Seive Sizes | % Passing | Specification | ||
| C Sand | IS 383 Zone II | |||
| 4.75 | 100 | 90-100 | ||
| 2.36 | 94.17 | 75-100 | ||
| 1.18 | 66.34 | 55-90 | ||
| 600 | 47.31 | 35-59 | ||
| 300 | 27.38 | 8-30 | ||
| 150 | 11.22 | 0-20 | ||
| IS Seive Sizes | 100% | 100% | 100% | 5.3% | 47.7% | 47% | Combined Passing | Specification |
| 20mm | 12.5mm | C Sand | 20mm | 12.5mm | C Sand | min-max | ||
| 40 | 100 | 100 | 100 | 5.3 | 47.7 | 47.00 | 100 | 100-100 |
| 20 | 91.93 | 100 | 100 | 4.87 | 47.7 | 47.00 | 99.57 | 95-100 |
| 4.75 | 0 | 0.64 | 100 | 0 | 0.31 | 47.00 | 47.31 | 30-50 |
| 0.6 | 0 | 0 | 47.31 | 0 | 0 | 22.24 | 22.24 | 10-35 |
| 0.15 | 0 | 0 | 11.22 | 0 | 0 | 5.2734 | 5.27 | 0-6 |
3. Target Mean Strength and Mix Proportioning
- As per MORTH the Target Mean Strength for M-60 Grade = 73Mpa
4. Target Mean Strength and Mix Proportioning
- As per technical specification max Water/Cement + Binder = 0.4
5. Selection of water/Cement Ratio (W/C)
Ref Tab 2 , IS 10262 , Maximum water content per cum for 20mm Aggregate = 186 litre for 50 mm slump= 186 + (0.12 * 186) (add 3% for every 25 mm increase )= 208.32 litBased on trials with super plasticizers, water content reduced by 15%,hence the arrived water content = 177.07lit, So Let us add water 177 lit
6. Cementious content Calculation
Water-Cementitious Ratio = 0.33Cementious content (Cement OPC 53 + GGBFS) = 536Say Cementitious content = 540 kg/m3Cement = 390 kg/m3Based on experience and lab trials,GGBS =150kg/m3 (Taking GGBS 27.77%)Based on experience and lab trials, Based on experience and lab trials, super plasticizer = 0.67 %
7. Calculation Aggregate content Calculation
Ref Tab 3 of IS 10262 , for Sand Zone II , volume of coarse aggregateper unit vol of total aggregate for 0.5 water-cement ratio = 0.62Adjust for W/c ratio : Add @ 0.01 for every decrease in 0.05= 0.034Therefore , corrected proportion = 0.654Adjust for pumpability , i.e decrese by 10% = 0.59 %Based on experience Considering Volume of coarse aggregate = 0.53Therefore, Volume of Fine aggregate = 0.47
8. Mix volume Calculation per cubic meter of concrete
a) Volume of concrete = 1 m3 b) Volume of cement = (Mass of cement /specific gravity of cement) × 1000 =390/(3.15×1000)= 0.124 m3c) Volume of GGBFS=(Mass of GGBFS/specific gravity of GGBFS )× 1000=(150/2.91)x1000=0.0515 d) Volume of water = (Mass of water /specific gravity of water)× 1000 = 0.177 m3 e) Volume of admixture = (Mass of admixture /specific gravity of admixture)× 1000 = (540×0.67)/(100×1.096×1000)=0.0033 m3 f) Volume of all in aggregate =[a-(b+c+d+e)] =1-(0.124+0.0515+0.177+0.0033)=0.6442= Say 0.644 m3 g) Mass of coarse aggregate(CA) 1) 20 mm = f × volume of CA × sp. gravity × % of 20mm × 1000 = 0.644*0.53*2.66*0.1*1000= 90.791 kg/m3, Say 91 kg/m3 2) 12 mm = f× volume of CA × sp. gravity × % of 12mm × 1000 = 0.644*0.53*2.64*0.9*1000 = 810.976 kg/m3, Say 811 kg/m3 g) Mass of Fine aggregate = f × volume of FA × sp. gravity × 1000 0.644*0.47*2.59*1000 = 783.941 kg/m3 Say 784 kg/m39. Details of Mix Design
- cement = 390 kg
- GGBFS =150 kg
- 20mm = 91 kg
- 12mm = 811 kg
- Crushed stone sand = 784 kg
- Chemical admixture = 3.62 kg
- Free Water = 177 kg
- Water-Cement Ratio = 0.33
- Concrete density = 2406 kg/m3
- Cement : Ultratech OPC 53 grade confirming to IS 269
- Specific Gravity of cement : 3.15
- JSW-GGBFS Confirming to IS 12089
- Specific Gravity of GGBFS: 2.91
- Chemical Admixture : FOSROC Auramix 400
- Specific Gravity of Admixture : 1.096
- JSW-GGBFS Confirming to IS 12089
- Specific Gravity
- Coarse aggregate
- 20mm : 2.66
- 12.5mm : 2.64
- Ratio of aggregate: 20mm-10% & 12.5mm-90%
- Coarse aggregate
- Fine aggregate
- Crushed stone aggregate : 2.59
- Fine aggregate
- Water: 1
- Specific Gravity
- Water Absorption
- Coarse aggregate
- 20mm : 0.29%
- 12.5mm : 0.36%
- Coarse aggregate
- Fine aggregate
- Crushed stone aggregate : 2.88%
- Fine aggregate
- Free Surface Moisture
- Fine aggregate : Nil
- Coarse aggregate: Nil
- Free Surface Moisture
- Sieve Analysis
- Coarse aggregate:
- Sieve Analysis
- Water Absorption
| IS Seive Sizes | % Passing | IS Requirement as per IS 383 Table 7 | Ratio | Combined 100% | Confirming to IS 383 table 7 | ||||||
| Single Sized | Graded | 10% | 90% | ||||||||
| 20 mm | 12.5 mm | 20 mm | 12.5 mm | 12.5 mm | 20 mm | 12.5 mm | |||||
| 20 | 91.93 | 100 | 85-100 | 100 | 100 | 9.19 | 90.00 | 99.19 | 90-100 | ||
| 12.5 | 0 | 98.78 | – | 85-100 | 90-100 | 0.00 | 88.90 | 88.90 | – | ||
| 10 | 0.44 | 52.08 | 0-20 | 0 – 45 | 40 – 85 | 0.04 | 46.87 | 46.92 | 25-55 | ||
| 4.75 | 0.2 | 0.64 | 0-5 | 0-10 | 0 – 10 | 0.02 | 0.576 | 0.60 | 0-10 | ||
| PAN | 0 | 0 | – | – | – | 0 | 0 | 0.00 | |||
- Fine Aggregate: Confirming to grading Zone II of table 4 of IS 383 Note:- as per field trials for pumpable concrete fine aggregate should pass zone II; According to IS 383 clause No. 31.2.2 allows to use crushed stone sand as fine aggregate for concrete .According to IS 383-2016 for crushed stone sand, the permeassible limit on 150 micron IS sieve is increased to20%.
| IS Seive Sizes | % Passing | Specification | ||
| C Sand | IS 383 Zone II | |||
| 4.75 | 100 | 90-100 | ||
| 2.36 | 94.17 | 75-100 | ||
| 1.18 | 66.34 | 55-90 | ||
| 600 | 47.31 | 35-59 | ||
| 300 | 27.38 | 8-30 | ||
| 150 | 11.22 | 0-20 | ||
| IS Seive Sizes | 100% | 100% | 100% | 5.3% | 47.7% | 47% | Combined Passing | Specification |
| 20mm | 12.5mm | C Sand | 20mm | 12.5mm | C Sand | min-max | ||
| 40 | 100 | 100 | 100 | 5.3 | 47.7 | 47.00 | 100 | 100-100 |
| 20 | 91.93 | 100 | 100 | 4.87 | 47.7 | 47.00 | 99.57 | 95-100 |
| 4.75 | 0 | 0.64 | 100 | 0 | 0.31 | 47.00 | 47.31 | 30-50 |
| 0.6 | 0 | 0 | 47.31 | 0 | 0 | 22.24 | 22.24 | 10-35 |
| 0.15 | 0 | 0 | 11.22 | 0 | 0 | 5.2734 | 5.27 | 0-6 |
3. Target Mean Strength and Mix Proportioning
- As per MORTH the Target Mean Strength for M-60 Grade = 73Mpa
4. Target Mean Strength and Mix Proportioning
- As per technical specification max Water/Cement + Binder = 0.4
5. Selection of water/Cement Ratio (W/C)
Ref Tab 2 , IS 10262 , Maximum water content per cum for 20mm Aggregate = 186 litre for 50 mm slump= 186 + (0.12 * 186) (add 3% for every 25 mm increase )= 208.32 litBased on trials with super plasticizers, water content reduced by 15%,hence the arrived water content = 177.07lit, So Let us add water 177 lit
6. Cementious content Calculation
Water-Cementitious Ratio = 0.33Cementious content (Cement OPC 53 + GGBFS) = 536Say Cementitious content = 540 kg/m3Cement = 390 kg/m3Based on experience and lab trials,GGBS =150kg/m3 (Taking GGBS 27.77%)Based on experience and lab trials, Based on experience and lab trials, super plasticizer = 0.67 %
7. Calculation Aggregate content Calculation
Ref Tab 3 of IS 10262 , for Sand Zone II , volume of coarse aggregateper unit vol of total aggregate for 0.5 water-cement ratio = 0.62Adjust for W/c ratio : Add @ 0.01 for every decrease in 0.05= 0.034Therefore , corrected proportion = 0.654Adjust for pumpability , i.e decrese by 10% = 0.59 %Based on experience Considering Volume of coarse aggregate = 0.53Therefore, Volume of Fine aggregate = 0.47
8. Mix volume Calculation per cubic meter of concrete
a) Volume of concrete = 1 m3 b) Volume of cement = (Mass of cement /specific gravity of cement) × 1000 =390/(3.15×1000)= 0.124 m3c) Volume of GGBFS=(Mass of GGBFS/specific gravity of GGBFS )× 1000=(150/2.91)x1000=0.0515 d) Volume of water = (Mass of water /specific gravity of water)× 1000 = 0.177 m3 e) Volume of admixture = (Mass of admixture /specific gravity of admixture)× 1000 = (540×0.67)/(100×1.096×1000)=0.0033 m3 f) Volume of all in aggregate =[a-(b+c+d+e)] =1-(0.124+0.0515+0.177+0.0033)=0.6442= Say 0.644 m3 g) Mass of coarse aggregate(CA) 1) 20 mm = f × volume of CA × sp. gravity × % of 20mm × 1000 = 0.644*0.53*2.66*0.1*1000= 90.791 kg/m3, Say 91 kg/m3 2) 12 mm = f× volume of CA × sp. gravity × % of 12mm × 1000 = 0.644*0.53*2.64*0.9*1000 = 810.976 kg/m3, Say 811 kg/m3 g) Mass of Fine aggregate = f × volume of FA × sp. gravity × 1000 0.644*0.47*2.59*1000 = 783.941 kg/m3 Say 784 kg/m39. Details of Mix Design
- cement = 390 kg
- GGBFS =150 kg
- 20mm = 91 kg
- 12mm = 811 kg
- Crushed stone sand = 784 kg
- Chemical admixture = 3.62 kg
- Free Water = 177 kg
- Water-Cement Ratio = 0.33
- Concrete density = 2406 kg/m3
- JSW-GGBFS Confirming to IS 12089
- Specific Gravity of GGBFS: 2.91
- Chemical Admixture : FOSROC Auramix 400
- Specific Gravity of Admixture : 1.096
- JSW-GGBFS Confirming to IS 12089
- Specific Gravity
- Coarse aggregate
- 20mm : 2.66
- 12.5mm : 2.64
- Ratio of aggregate: 20mm-10% & 12.5mm-90%
- Coarse aggregate
- Fine aggregate
- Crushed stone aggregate : 2.59
- Fine aggregate
- Water: 1
- Specific Gravity
- Water Absorption
- Coarse aggregate
- 20mm : 0.29%
- 12.5mm : 0.36%
- Coarse aggregate
- Fine aggregate
- Crushed stone aggregate : 2.88%
- Fine aggregate
- Free Surface Moisture
- Fine aggregate : Nil
- Coarse aggregate: Nil
- Free Surface Moisture
- Sieve Analysis
- Coarse aggregate:
- Sieve Analysis
- Water Absorption
| IS Seive Sizes | % Passing | IS Requirement as per IS 383 Table 7 | Ratio | Combined 100% | Confirming to IS 383 table 7 | ||||||
| Single Sized | Graded | 10% | 90% | ||||||||
| 20 mm | 12.5 mm | 20 mm | 12.5 mm | 12.5 mm | 20 mm | 12.5 mm | |||||
| 20 | 91.93 | 100 | 85-100 | 100 | 100 | 9.19 | 90.00 | 99.19 | 90-100 | ||
| 12.5 | 0 | 98.78 | – | 85-100 | 90-100 | 0.00 | 88.90 | 88.90 | – | ||
| 10 | 0.44 | 52.08 | 0-20 | 0 – 45 | 40 – 85 | 0.04 | 46.87 | 46.92 | 25-55 | ||
| 4.75 | 0.2 | 0.64 | 0-5 | 0-10 | 0 – 10 | 0.02 | 0.576 | 0.60 | 0-10 | ||
| PAN | 0 | 0 | – | – | – | 0 | 0 | 0.00 | |||
- Fine Aggregate: Confirming to grading Zone II of Table 4 of IS 383. Note:- as per field trials for pumpable concrete, fine aggregate should pass Zone II. According to IS 383 clause No. 31.2.2, it allows the use of crushed stone sand as fine aggregate for concrete. According to IS 383-2016 for crushed stone sand, the permeassible limit on 150 micron IS sieve is increased to20%.
| IS Seive Sizes | % Passing | Specification | ||
| C Sand | IS 383 Zone II | |||
| 4.75 | 100 | 90-100 | ||
| 2.36 | 94.17 | 75-100 | ||
| 1.18 | 66.34 | 55-90 | ||
| 600 | 47.31 | 35-59 | ||
| 300 | 27.38 | 8-30 | ||
| 150 | 11.22 | 0-20 | ||
| IS Seive Sizes | 100% | 100% | 100% | 5.3% | 47.7% | 47% | Combined Passing | Specification |
| 20mm | 12.5mm | C Sand | 20mm | 12.5mm | C Sand | min-max | ||
| 40 | 100 | 100 | 100 | 5.3 | 47.7 | 47.00 | 100 | 100-100 |
| 20 | 91.93 | 100 | 100 | 4.87 | 47.7 | 47.00 | 99.57 | 95-100 |
| 4.75 | 0 | 0.64 | 100 | 0 | 0.31 | 47.00 | 47.31 | 30-50 |
| 0.6 | 0 | 0 | 47.31 | 0 | 0 | 22.24 | 22.24 | 10-35 |
| 0.15 | 0 | 0 | 11.22 | 0 | 0 | 5.2734 | 5.27 | 0-6 |
3. Target Mean Strength and Mix Proportioning
- As per MORTH the Target Mean Strength for M-60 Grade = 73Mpa
4. Target Mean Strength and Mix Proportioning
- As per technical specification max Water/Cement + Binder = 0.4
5. Selection of water/Cement Ratio (W/C)
Ref Tab 2 , IS 10262 , Maximum water content per cum for 20mm Aggregate = 186 litre for 50 mm slump= 186 + (0.12 * 186) (add 3% for every 25 mm increase )= 208.32 litBased on trials with super plasticizers, water content reduced by 15%,hence the arrived water content = 177.07lit, So Let us add water 177 lit
6. Cementious content Calculation
Water-Cementitious Ratio = 0.33Cementious content (Cement OPC 53 + GGBFS) = 536Say Cementitious content = 540 kg/m3Cement = 390 kg/m3Based on experience and lab trials,GGBS =150kg/m3 (Taking GGBS 27.77%)Based on experience and lab trials, Based on experience and lab trials, super plasticizer = 0.67 %
7. Calculation Aggregate content Calculation
Ref Tab 3 of IS 10262 , for Sand Zone II , volume of coarse aggregateper unit vol of total aggregate for 0.5 water-cement ratio = 0.62Adjust for W/c ratio : Add @ 0.01 for every decrease in 0.05= 0.034Therefore , corrected proportion = 0.654Adjust for pumpability , i.e decrese by 10% = 0.59 %Based on experience Considering Volume of coarse aggregate = 0.53Therefore, Volume of Fine aggregate = 0.47
8. Mix volume Calculation per cubic meter of concrete
a) Volume of concrete = 1 m3 b) Volume of cement = (Mass of cement /specific gravity of cement) × 1000 =390/(3.15×1000)= 0.124 m3c) Volume of GGBFS=(Mass of GGBFS/specific gravity of GGBFS )× 1000=(150/2.91)x1000=0.0515 d) Volume of water = (Mass of water /specific gravity of water)× 1000 = 0.177 m3 e) Volume of admixture = (Mass of admixture /specific gravity of admixture)× 1000 = (540×0.67)/(100×1.096×1000)=0.0033 m3 f) Volume of all in aggregate =[a-(b+c+d+e)] =1-(0.124+0.0515+0.177+0.0033)=0.6442= Say 0.644 m3 g) Mass of coarse aggregate(CA) 1) 20 mm = f × volume of CA × sp. gravity × % of 20mm × 1000 = 0.644*0.53*2.66*0.1*1000= 90.791 kg/m3, Say 91 kg/m3 2) 12 mm = f× volume of CA × sp. gravity × % of 12mm × 1000 = 0.644*0.53*2.64*0.9*1000 = 810.976 kg/m3, Say 811 kg/m3 g) Mass of Fine aggregate = f × volume of FA × sp. gravity × 1000 0.644*0.47*2.59*1000 = 783.941 kg/m3 Say 784 kg/m39. Details of Mix Design
- cement = 390 kg
- GGBFS =150 kg
- 20mm = 91 kg
- 12mm = 811 kg
- Crushed stone sand = 784 kg
- Chemical admixture = 3.62 kg
- Free Water = 177 kg
- Water-Cement Ratio = 0.33
- Concrete density = 2406 kg/m3
- Cement : Ultratech OPC 53 grade confirming to IS 269
- Specific Gravity of cement : 3.15
- JSW-GGBFS Confirming to IS 12089
- Specific Gravity of GGBFS: 2.91
- Chemical Admixture : FOSROC Auramix 400
- Specific Gravity of Admixture : 1.096
- JSW-GGBFS Confirming to IS 12089
- Specific Gravity
- Coarse aggregate
- 20mm : 2.66
- 12.5mm : 2.64
- Ratio of aggregate: 20mm-10% & 12.5mm-90%
- Coarse aggregate
- Fine aggregate
- Crushed stone aggregate : 2.59
- Fine aggregate
- Water: 1
- Specific Gravity
- Water Absorption
- Coarse aggregate
- 20mm : 0.29%
- 12.5mm : 0.36%
- Coarse aggregate
- Fine aggregate
- Crushed stone aggregate : 2.88%
- Fine aggregate
- Free Surface Moisture
- Fine aggregate : Nil
- Coarse aggregate: Nil
- Free Surface Moisture
- Sieve Analysis
- Coarse aggregate:
- Sieve Analysis
- Water Absorption
| IS Seive Sizes | % Passing | IS Requirement as per IS 383 Table 7 | Ratio | Combined 100% | Confirming to IS 383 table 7 | ||||||
| Single Sized | Graded | 10% | 90% | ||||||||
| 20 mm | 12.5 mm | 20 mm | 12.5 mm | 12.5 mm | 20 mm | 12.5 mm | |||||
| 20 | 91.93 | 100 | 85-100 | 100 | 100 | 9.19 | 90.00 | 99.19 | 90-100 | ||
| 12.5 | 0 | 98.78 | – | 85-100 | 90-100 | 0.00 | 88.90 | 88.90 | – | ||
| 10 | 0.44 | 52.08 | 0-20 | 0 – 45 | 40 – 85 | 0.04 | 46.87 | 46.92 | 25-55 | ||
| 4.75 | 0.2 | 0.64 | 0-5 | 0-10 | 0 – 10 | 0.02 | 0.576 | 0.60 | 0-10 | ||
| PAN | 0 | 0 | – | – | – | 0 | 0 | 0.00 | |||
- Fine Aggregate: Confirming to grading Zone II of table 4 of IS 383 Note:- as per field trials for pumpable concrete fine aggregate should pass zone II; According to IS 383 clause No. 31.2.2 allows to use crushed stone sand as fine aggregate for concrete .According to IS 383-2016 for crushed stone sand, the permeassible limit on 150 micron IS sieve is increased to20%.
| IS Seive Sizes | % Passing | Specification | ||
| C Sand | IS 383 Zone II | |||
| 4.75 | 100 | 90-100 | ||
| 2.36 | 94.17 | 75-100 | ||
| 1.18 | 66.34 | 55-90 | ||
| 600 | 47.31 | 35-59 | ||
| 300 | 27.38 | 8-30 | ||
| 150 | 11.22 | 0-20 | ||
| IS Seive Sizes | 100% | 100% | 100% | 5.3% | 47.7% | 47% | Combined Passing | Specification |
| 20mm | 12.5mm | C Sand | 20mm | 12.5mm | C Sand | min-max | ||
| 40 | 100 | 100 | 100 | 5.3 | 47.7 | 47.00 | 100 | 100-100 |
| 20 | 91.93 | 100 | 100 | 4.87 | 47.7 | 47.00 | 99.57 | 95-100 |
| 4.75 | 0 | 0.64 | 100 | 0 | 0.31 | 47.00 | 47.31 | 30-50 |
| 0.6 | 0 | 0 | 47.31 | 0 | 0 | 22.24 | 22.24 | 10-35 |
| 0.15 | 0 | 0 | 11.22 | 0 | 0 | 5.2734 | 5.27 | 0-6 |
3. Target Mean Strength and Mix Proportioning
- As per MORTH the Target Mean Strength for M-60 Grade = 73Mpa
4. Target Mean Strength and Mix Proportioning
- As per technical specification max Water/Cement + Binder = 0.4
5. Selection of water/Cement Ratio (W/C)
Ref Tab 2 , IS 10262 , Maximum water content per cum for 20mm Aggregate = 186 litre for 50 mm slump= 186 + (0.12 * 186) (add 3% for every 25 mm increase )= 208.32 litBased on trials with super plasticizers, water content reduced by 15%,hence the arrived water content = 177.07lit, So Let us add water 177 lit
6. Cementious content Calculation
Water-Cementitious Ratio = 0.33Cementious content (Cement OPC 53 + GGBFS) = 536Say Cementitious content = 540 kg/m3Cement = 390 kg/m3Based on experience and lab trials,GGBS =150kg/m3 (Taking GGBS 27.77%)Based on experience and lab trials, Based on experience and lab trials, super plasticizer = 0.67 %
7. Calculation Aggregate content Calculation
Ref Tab 3 of IS 10262 , for Sand Zone II , volume of coarse aggregateper unit vol of total aggregate for 0.5 water-cement ratio = 0.62Adjust for W/c ratio : Add @ 0.01 for every decrease in 0.05= 0.034Therefore , corrected proportion = 0.654Adjust for pumpability , i.e decrese by 10% = 0.59 %Based on experience Considering Volume of coarse aggregate = 0.53Therefore, Volume of Fine aggregate = 0.47
8. Mix volume Calculation per cubic meter of concrete
a) Volume of concrete = 1 m3 b) Volume of cement = (Mass of cement /specific gravity of cement) × 1000 =390/(3.15×1000)= 0.124 m3c) Volume of GGBFS=(Mass of GGBFS/specific gravity of GGBFS )× 1000=(150/2.91)x1000=0.0515 d) Volume of water = (Mass of water /specific gravity of water)× 1000 = 0.177 m3 e) Volume of admixture = (Mass of admixture /specific gravity of admixture)× 1000 = (540×0.67)/(100×1.096×1000)=0.0033 m3 f) Volume of all in aggregate =[a-(b+c+d+e)] =1-(0.124+0.0515+0.177+0.0033)=0.6442= Say 0.644 m3 g) Mass of coarse aggregate(CA) 1) 20 mm = f × volume of CA × sp. gravity × % of 20mm × 1000 = 0.644*0.53*2.66*0.1*1000= 90.791 kg/m3, Say 91 kg/m3 2) 12 mm = f× volume of CA × sp. gravity × % of 12mm × 1000 = 0.644*0.53*2.64*0.9*1000 = 810.976 kg/m3, Say 811 kg/m3 g) Mass of Fine aggregate = f × volume of FA × sp. gravity × 1000 0.644*0.47*2.59*1000 = 783.941 kg/m3 Say 784 kg/m39. Details of Mix Design
- cement = 390 kg
- GGBFS =150 kg
- 20mm = 91 kg
- 12mm = 811 kg
- Crushed stone sand = 784 kg
- Chemical admixture = 3.62 kg
- Free Water = 177 kg
- Water-Cement Ratio = 0.33
- Concrete density = 2406 kg/m3
- Cement : Ultratech OPC 53 grade confirming to IS 269
- Specific Gravity of cement : 3.15
- JSW-GGBFS Confirming to IS 12089
- Specific Gravity of GGBFS: 2.91
- Chemical Admixture : FOSROC Auramix 400
- Specific Gravity of Admixture : 1.096
- JSW-GGBFS Confirming to IS 12089
- Specific Gravity
- Coarse aggregate
- 20mm : 2.66
- 12.5mm : 2.64
- Ratio of aggregate: 20mm-10% & 12.5mm-90%
- Coarse aggregate
- Fine aggregate
- Crushed stone aggregate : 2.59
- Fine aggregate
- Water: 1
- Specific Gravity
- Water Absorption
- Coarse aggregate
- 20mm : 0.29%
- 12.5mm : 0.36%
- Coarse aggregate
- Fine aggregate
- Crushed stone aggregate : 2.88%
- Fine aggregate
- Free Surface Moisture
- Fine aggregate : Nil
- Coarse aggregate: Nil
- Free Surface Moisture
- Sieve Analysis
- Coarse aggregate:
- Sieve Analysis
- Water Absorption
| IS Seive Sizes | % Passing | IS Requirement as per IS 383 Table 7 | Ratio | Combined 100% | Confirming to IS 383 table 7 | ||||||
| Single Sized | Graded | 10% | 90% | ||||||||
| 20 mm | 12.5 mm | 20 mm | 12.5 mm | 12.5 mm | 20 mm | 12.5 mm | |||||
| 20 | 91.93 | 100 | 85-100 | 100 | 100 | 9.19 | 90.00 | 99.19 | 90-100 | ||
| 12.5 | 0 | 98.78 | – | 85-100 | 90-100 | 0.00 | 88.90 | 88.90 | – | ||
| 10 | 0.44 | 52.08 | 0-20 | 0 – 45 | 40 – 85 | 0.04 | 46.87 | 46.92 | 25-55 | ||
| 4.75 | 0.2 | 0.64 | 0-5 | 0-10 | 0 – 10 | 0.02 | 0.576 | 0.60 | 0-10 | ||
| PAN | 0 | 0 | – | – | – | 0 | 0 | 0.00 | |||
- Fine Aggregate: Confirming to grading Zone II of table 4 of IS 383 Note:- as per field trials for pumpable concrete fine aggregate should pass zone II; According to IS 383 clause No. 31.2.2 allows to use crushed stone sand as fine aggregate for concrete .According to IS 383-2016 for crushed stone sand, the permeassible limit on 150 micron IS sieve is increased to20%.
| IS Seive Sizes | % Passing | Specification | ||
| C Sand | IS 383 Zone II | |||
| 4.75 | 100 | 90-100 | ||
| 2.36 | 94.17 | 75-100 | ||
| 1.18 | 66.34 | 55-90 | ||
| 600 | 47.31 | 35-59 | ||
| 300 | 27.38 | 8-30 | ||
| 150 | 11.22 | 0-20 | ||
| IS Seive Sizes | 100% | 100% | 100% | 5.3% | 47.7% | 47% | Combined Passing | Specification |
| 20mm | 12.5mm | C Sand | 20mm | 12.5mm | C Sand | min-max | ||
| 40 | 100 | 100 | 100 | 5.3 | 47.7 | 47.00 | 100 | 100-100 |
| 20 | 91.93 | 100 | 100 | 4.87 | 47.7 | 47.00 | 99.57 | 95-100 |
| 4.75 | 0 | 0.64 | 100 | 0 | 0.31 | 47.00 | 47.31 | 30-50 |
| 0.6 | 0 | 0 | 47.31 | 0 | 0 | 22.24 | 22.24 | 10-35 |
| 0.15 | 0 | 0 | 11.22 | 0 | 0 | 5.2734 | 5.27 | 0-6 |
3. Target Mean Strength and Mix Proportioning
- As per MORTH the Target Mean Strength for M-60 Grade = 73Mpa
4. Target Mean Strength and Mix Proportioning
- As per technical specification max Water/Cement + Binder = 0.4
5. Selection of water/Cement Ratio (W/C)
Ref Tab 2 , IS 10262 , Maximum water content per cum for 20mm Aggregate = 186 litre for 50 mm slump= 186 + (0.12 * 186) (add 3% for every 25 mm increase )= 208.32 litBased on trials with super plasticizers, water content reduced by 15%,hence the arrived water content = 177.07lit, So Let us add water 177 lit
6. Cementious content Calculation
Water-Cementitious Ratio = 0.33Cementious content (Cement OPC 53 + GGBFS) = 536Say Cementitious content = 540 kg/m3Cement = 390 kg/m3Based on experience and lab trials,GGBS =150kg/m3 (Taking GGBS 27.77%)Based on experience and lab trials, Based on experience and lab trials, super plasticizer = 0.67 %
7. Calculation Aggregate content Calculation
Ref Tab 3 of IS 10262 , for Sand Zone II , volume of coarse aggregateper unit vol of total aggregate for 0.5 water-cement ratio = 0.62Adjust for W/c ratio : Add @ 0.01 for every decrease in 0.05= 0.034Therefore , corrected proportion = 0.654Adjust for pumpability , i.e decrese by 10% = 0.59 %Based on experience Considering Volume of coarse aggregate = 0.53Therefore, Volume of Fine aggregate = 0.47
8. Mix volume Calculation per cubic meter of concrete
a) Volume of concrete = 1 m3 b) Volume of cement = (Mass of cement /specific gravity of cement) × 1000 =390/(3.15×1000)= 0.124 m3c) Volume of GGBFS=(Mass of GGBFS/specific gravity of GGBFS )× 1000=(150/2.91)x1000=0.0515 d) Volume of water = (Mass of water /specific gravity of water)× 1000 = 0.177 m3 e) Volume of admixture = (Mass of admixture /specific gravity of admixture)× 1000 = (540×0.67)/(100×1.096×1000)=0.0033 m3 f) Volume of all in aggregate =[a-(b+c+d+e)] =1-(0.124+0.0515+0.177+0.0033)=0.6442= Say 0.644 m3 g) Mass of coarse aggregate(CA) 1) 20 mm = f × volume of CA × sp. gravity × % of 20mm × 1000 = 0.644*0.53*2.66*0.1*1000= 90.791 kg/m3, Say 91 kg/m3 2) 12 mm = f× volume of CA × sp. gravity × % of 12mm × 1000 = 0.644*0.53*2.64*0.9*1000 = 810.976 kg/m3, Say 811 kg/m3 g) Mass of Fine aggregate = f × volume of FA × sp. gravity × 1000 0.644*0.47*2.59*1000 = 783.941 kg/m3 Say 784 kg/m39. Details of Mix Design
- cement = 390 kg
- GGBFS =150 kg
- 20mm = 91 kg
- 12mm = 811 kg
- Crushed stone sand = 784 kg
- Chemical admixture = 3.62 kg
- Free Water = 177 kg
- Water-Cement Ratio = 0.33
- Concrete density = 2406 kg/m3
- JSW-GGBFS Confirming to IS 12089
- Specific Gravity of GGBFS: 2.91
- Chemical Admixture : FOSROC Auramix 400
- Specific Gravity of Admixture : 1.096
- JSW-GGBFS Confirming to IS 12089
- Specific Gravity
- Coarse aggregate
- 20mm : 2.66
- 12.5mm : 2.64
- Ratio of aggregate: 20mm-10% & 12.5mm-90%
- Coarse aggregate
- Fine aggregate
- Crushed stone aggregate : 2.59
- Fine aggregate
- Water: 1
- Specific Gravity
- Water Absorption
- Coarse aggregate
- 20mm : 0.29%
- 12.5mm : 0.36%
- Coarse aggregate
- Fine aggregate
- Crushed stone aggregate : 2.88%
- Fine aggregate
- Free Surface Moisture
- Fine aggregate : Nil
- Coarse aggregate: Nil
- Free Surface Moisture
- Sieve Analysis
- Coarse aggregate:
- Sieve Analysis
- Water Absorption
| IS Seive Sizes | % Passing | IS Requirement as per IS 383 Table 7 | Ratio | Combined 100% | Confirming to IS 383 table 7 | ||||||
| Single Sized | Graded | 10% | 90% | ||||||||
| 20 mm | 12.5 mm | 20 mm | 12.5 mm | 12.5 mm | 20 mm | 12.5 mm | |||||
| 20 | 91.93 | 100 | 85-100 | 100 | 100 | 9.19 | 90.00 | 99.19 | 90-100 | ||
| 12.5 | 0 | 98.78 | – | 85-100 | 90-100 | 0.00 | 88.90 | 88.90 | – | ||
| 10 | 0.44 | 52.08 | 0-20 | 0 – 45 | 40 – 85 | 0.04 | 46.87 | 46.92 | 25-55 | ||
| 4.75 | 0.2 | 0.64 | 0-5 | 0-10 | 0 – 10 | 0.02 | 0.576 | 0.60 | 0-10 | ||
| PAN | 0 | 0 | – | – | – | 0 | 0 | 0.00 | |||
- Fine Aggregate: Confirming to grading Zone II of Table 4 of IS 383. Note:- as per field trials for pumpable concrete, fine aggregate should pass Zone II. According to IS 383 clause No. 31.2.2, it allows the use of crushed stone sand as fine aggregate for concrete. According to IS 383-2016 for crushed stone sand, the permeassible limit on 150 micron IS sieve is increased to20%.
| IS Seive Sizes | % Passing | Specification | ||
| C Sand | IS 383 Zone II | |||
| 4.75 | 100 | 90-100 | ||
| 2.36 | 94.17 | 75-100 | ||
| 1.18 | 66.34 | 55-90 | ||
| 600 | 47.31 | 35-59 | ||
| 300 | 27.38 | 8-30 | ||
| 150 | 11.22 | 0-20 | ||
| IS Seive Sizes | 100% | 100% | 100% | 5.3% | 47.7% | 47% | Combined Passing | Specification |
| 20mm | 12.5mm | C Sand | 20mm | 12.5mm | C Sand | min-max | ||
| 40 | 100 | 100 | 100 | 5.3 | 47.7 | 47.00 | 100 | 100-100 |
| 20 | 91.93 | 100 | 100 | 4.87 | 47.7 | 47.00 | 99.57 | 95-100 |
| 4.75 | 0 | 0.64 | 100 | 0 | 0.31 | 47.00 | 47.31 | 30-50 |
| 0.6 | 0 | 0 | 47.31 | 0 | 0 | 22.24 | 22.24 | 10-35 |
| 0.15 | 0 | 0 | 11.22 | 0 | 0 | 5.2734 | 5.27 | 0-6 |
3. Target Mean Strength and Mix Proportioning
- As per MORTH the Target Mean Strength for M-60 Grade = 73Mpa
4. Target Mean Strength and Mix Proportioning
- As per technical specification max Water/Cement + Binder = 0.4
5. Selection of water/Cement Ratio (W/C)
Ref Tab 2 , IS 10262 , Maximum water content per cum for 20mm Aggregate = 186 litre for 50 mm slump= 186 + (0.12 * 186) (add 3% for every 25 mm increase )= 208.32 litBased on trials with super plasticizers, water content reduced by 15%,hence the arrived water content = 177.07lit, So Let us add water 177 lit
6. Cementious content Calculation
Water-Cementitious Ratio = 0.33Cementious content (Cement OPC 53 + GGBFS) = 536Say Cementitious content = 540 kg/m3Cement = 390 kg/m3Based on experience and lab trials,GGBS =150kg/m3 (Taking GGBS 27.77%)Based on experience and lab trials, Based on experience and lab trials, super plasticizer = 0.67 %
7. Calculation Aggregate content Calculation
Ref Tab 3 of IS 10262 , for Sand Zone II , volume of coarse aggregateper unit vol of total aggregate for 0.5 water-cement ratio = 0.62Adjust for W/c ratio : Add @ 0.01 for every decrease in 0.05= 0.034Therefore , corrected proportion = 0.654Adjust for pumpability , i.e decrese by 10% = 0.59 %Based on experience Considering Volume of coarse aggregate = 0.53Therefore, Volume of Fine aggregate = 0.47
8. Mix volume Calculation per cubic meter of concrete
a) Volume of concrete = 1 m3 b) Volume of cement = (Mass of cement /specific gravity of cement) × 1000 =390/(3.15×1000)= 0.124 m3c) Volume of GGBFS=(Mass of GGBFS/specific gravity of GGBFS )× 1000=(150/2.91)x1000=0.0515 d) Volume of water = (Mass of water /specific gravity of water)× 1000 = 0.177 m3 e) Volume of admixture = (Mass of admixture /specific gravity of admixture)× 1000 = (540×0.67)/(100×1.096×1000)=0.0033 m3 f) Volume of all in aggregate =[a-(b+c+d+e)] =1-(0.124+0.0515+0.177+0.0033)=0.6442= Say 0.644 m3 g) Mass of coarse aggregate(CA) 1) 20 mm = f × volume of CA × sp. gravity × % of 20mm × 1000 = 0.644*0.53*2.66*0.1*1000= 90.791 kg/m3, Say 91 kg/m3 2) 12 mm = f× volume of CA × sp. gravity × % of 12mm × 1000 = 0.644*0.53*2.64*0.9*1000 = 810.976 kg/m3, Say 811 kg/m3 g) Mass of Fine aggregate = f × volume of FA × sp. gravity × 1000 0.644*0.47*2.59*1000 = 783.941 kg/m3 Say 784 kg/m39. Details of Mix Design
- cement = 390 kg
- GGBFS =150 kg
- 20mm = 91 kg
- 12mm = 811 kg
- Crushed stone sand = 784 kg
- Chemical admixture = 3.62 kg
- Free Water = 177 kg
- Water-Cement Ratio = 0.33
- Concrete density = 2406 kg/m3
- Cement : Ultratech OPC 53 grade confirming to IS 269
- Specific Gravity of cement : 3.15
- JSW-GGBFS Confirming to IS 12089
- Specific Gravity of GGBFS: 2.91
- Chemical Admixture : FOSROC Auramix 400
- Specific Gravity of Admixture : 1.096
- JSW-GGBFS Confirming to IS 12089
- Specific Gravity
- Coarse aggregate
- 20mm : 2.66
- 12.5mm : 2.64
- Ratio of aggregate: 20mm-10% & 12.5mm-90%
- Coarse aggregate
- Fine aggregate
- Crushed stone aggregate : 2.59
- Fine aggregate
- Water: 1
- Specific Gravity
- Water Absorption
- Coarse aggregate
- 20mm : 0.29%
- 12.5mm : 0.36%
- Coarse aggregate
- Fine aggregate
- Crushed stone aggregate : 2.88%
- Fine aggregate
- Free Surface Moisture
- Fine aggregate : Nil
- Coarse aggregate: Nil
- Free Surface Moisture
- Sieve Analysis
- Coarse aggregate:
- Sieve Analysis
- Water Absorption
| IS Seive Sizes | % Passing | IS Requirement as per IS 383 Table 7 | Ratio | Combined 100% | Confirming to IS 383 table 7 | ||||||
| Single Sized | Graded | 10% | 90% | ||||||||
| 20 mm | 12.5 mm | 20 mm | 12.5 mm | 12.5 mm | 20 mm | 12.5 mm | |||||
| 20 | 91.93 | 100 | 85-100 | 100 | 100 | 9.19 | 90.00 | 99.19 | 90-100 | ||
| 12.5 | 0 | 98.78 | – | 85-100 | 90-100 | 0.00 | 88.90 | 88.90 | – | ||
| 10 | 0.44 | 52.08 | 0-20 | 0 – 45 | 40 – 85 | 0.04 | 46.87 | 46.92 | 25-55 | ||
| 4.75 | 0.2 | 0.64 | 0-5 | 0-10 | 0 – 10 | 0.02 | 0.576 | 0.60 | 0-10 | ||
| PAN | 0 | 0 | – | – | – | 0 | 0 | 0.00 | |||
- Fine Aggregate: Confirming to grading Zone II of table 4 of IS 383 Note:- as per field trials for pumpable concrete fine aggregate should pass zone II; According to IS 383 clause No. 31.2.2 allows to use crushed stone sand as fine aggregate for concrete .According to IS 383-2016 for crushed stone sand, the permeassible limit on 150 micron IS sieve is increased to20%.
| IS Seive Sizes | % Passing | Specification | ||
| C Sand | IS 383 Zone II | |||
| 4.75 | 100 | 90-100 | ||
| 2.36 | 94.17 | 75-100 | ||
| 1.18 | 66.34 | 55-90 | ||
| 600 | 47.31 | 35-59 | ||
| 300 | 27.38 | 8-30 | ||
| 150 | 11.22 | 0-20 | ||
| IS Seive Sizes | 100% | 100% | 100% | 5.3% | 47.7% | 47% | Combined Passing | Specification |
| 20mm | 12.5mm | C Sand | 20mm | 12.5mm | C Sand | min-max | ||
| 40 | 100 | 100 | 100 | 5.3 | 47.7 | 47.00 | 100 | 100-100 |
| 20 | 91.93 | 100 | 100 | 4.87 | 47.7 | 47.00 | 99.57 | 95-100 |
| 4.75 | 0 | 0.64 | 100 | 0 | 0.31 | 47.00 | 47.31 | 30-50 |
| 0.6 | 0 | 0 | 47.31 | 0 | 0 | 22.24 | 22.24 | 10-35 |
| 0.15 | 0 | 0 | 11.22 | 0 | 0 | 5.2734 | 5.27 | 0-6 |
3. Target Mean Strength and Mix Proportioning
- As per MORTH the Target Mean Strength for M-60 Grade = 73Mpa
4. Target Mean Strength and Mix Proportioning
- As per technical specification max Water/Cement + Binder = 0.4
5. Selection of water/Cement Ratio (W/C)
Ref Tab 2 , IS 10262 , Maximum water content per cum for 20mm Aggregate = 186 litre for 50 mm slump= 186 + (0.12 * 186) (add 3% for every 25 mm increase )= 208.32 litBased on trials with super plasticizers, water content reduced by 15%,hence the arrived water content = 177.07lit, So Let us add water 177 lit
6. Cementious content Calculation
Water-Cementitious Ratio = 0.33Cementious content (Cement OPC 53 + GGBFS) = 536Say Cementitious content = 540 kg/m3Cement = 390 kg/m3Based on experience and lab trials,GGBS =150kg/m3 (Taking GGBS 27.77%)Based on experience and lab trials, Based on experience and lab trials, super plasticizer = 0.67 %
7. Calculation Aggregate content Calculation
Ref Tab 3 of IS 10262 , for Sand Zone II , volume of coarse aggregateper unit vol of total aggregate for 0.5 water-cement ratio = 0.62Adjust for W/c ratio : Add @ 0.01 for every decrease in 0.05= 0.034Therefore , corrected proportion = 0.654Adjust for pumpability , i.e decrese by 10% = 0.59 %Based on experience Considering Volume of coarse aggregate = 0.53Therefore, Volume of Fine aggregate = 0.47
8. Mix volume Calculation per cubic meter of concrete
a) Volume of concrete = 1 m3 b) Volume of cement = (Mass of cement /specific gravity of cement) × 1000 =390/(3.15×1000)= 0.124 m3c) Volume of GGBFS=(Mass of GGBFS/specific gravity of GGBFS )× 1000=(150/2.91)x1000=0.0515 d) Volume of water = (Mass of water /specific gravity of water)× 1000 = 0.177 m3 e) Volume of admixture = (Mass of admixture /specific gravity of admixture)× 1000 = (540×0.67)/(100×1.096×1000)=0.0033 m3 f) Volume of all in aggregate =[a-(b+c+d+e)] =1-(0.124+0.0515+0.177+0.0033)=0.6442= Say 0.644 m3 g) Mass of coarse aggregate(CA) 1) 20 mm = f × volume of CA × sp. gravity × % of 20mm × 1000 = 0.644*0.53*2.66*0.1*1000= 90.791 kg/m3, Say 91 kg/m3 2) 12 mm = f× volume of CA × sp. gravity × % of 12mm × 1000 = 0.644*0.53*2.64*0.9*1000 = 810.976 kg/m3, Say 811 kg/m3 g) Mass of Fine aggregate = f × volume of FA × sp. gravity × 1000 0.644*0.47*2.59*1000 = 783.941 kg/m3 Say 784 kg/m39. Details of Mix Design
- cement = 390 kg
- GGBFS =150 kg
- 20mm = 91 kg
- 12mm = 811 kg
- Crushed stone sand = 784 kg
- Chemical admixture = 3.62 kg
- Free Water = 177 kg
- Water-Cement Ratio = 0.33
- Concrete density = 2406 kg/m3
RELATED POSTS
View all
Mix Design of M15 Grade of Concrete
January 22, 2022 | by tsquarecivilengineering
Mix Design of M50 Grade of Concrete with OPC Cement
January 22, 2022 | by tsquarecivilengineering
Mix Design of M35 Grade of Concrete
January 22, 2022 | by tsquarecivilengineering
