This article presents an illustrative initial trial mix design for M25 concrete using the general mix-proportioning procedure of IS 10262:2019.
The example is prepared for moderate-exposure reinforced concrete using OPC 53 cement, 20 mm crushed angular aggregate, 12.5 mm coarse aggregate, Zone II M-sand, a 100 mm target slump and a compatible superplasticizer.
Important: This is an educational initial trial mix and not a universal M25 concrete recipe. The final production mix must be confirmed through laboratory trials using the actual cement, aggregates, water, admixture, batching system and project requirements.
Page Contents
Important Exposure and Grade Note
For the selected moderate-exposure RCC condition, the durability requirements generally considered from IS 456 include:
- Maximum water–cement ratio: 0.50
- Minimum cement content: 300 kg/m³
- Minimum grade for reinforced concrete: M25
If the exposure condition, structural application, placement method or project specification changes, the mix must be redesigned.
This example is not intended for severe exposure, mass concrete, pumped concrete or special structural applications without separate verification.
1. Mix Stipulations
| Property | Adopted value |
|---|---|
| Grade of concrete | M25 |
| Characteristic compressive strength at 28 days | 25 N/mm² |
| Exposure condition | Moderate exposure for RCC |
| Cement | OPC 53 grade |
| Mineral admixture | None |
| Maximum nominal size of aggregate | 20 mm |
| Target slump | 100 mm |
| Concrete placement | Normal, non-pumped placement |
| Degree of supervision | Good |
| Coarse aggregate | Crushed angular aggregate |
| Fine aggregate | M-sand, assumed Zone II |
| Chemical admixture | Superplasticizer |
| Trial admixture dosage | 0.60% by mass of cement |
| Maximum water–cement ratio | 0.50 |
| Minimum cement content | 300 kg/m³ |
| Adopted external design water | 138 litres/m³ |
| Adopted cement content | 300 kg/m³ |
| Calculation-basis water–cement ratio | 0.46 |
| Aggregate condition | Saturated surface-dry condition |
The final dosage of superplasticizer and the final water–cement ratio must be confirmed through actual trial mixing.
2. Material Properties
2.1 Cement and Admixture
| Material | Property | Adopted value |
|---|---|---|
| Cement | Type | OPC 53 grade |
| Cement | Specific gravity | 3.15 |
| Superplasticizer | Type | High-range water-reducing admixture |
| Superplasticizer | Specific gravity | 1.09 |
| Superplasticizer dosage | Percentage by mass of cement | 0.60% |
The admixture dosage used here is only an initial trial assumption. The manufacturer’s technical datasheet, compatibility, setting behaviour and trial results must be checked before production.
2.2 Aggregate Specific Gravity
| Aggregate | Specific gravity |
|---|---|
| 20 mm coarse aggregate | 2.70 |
| 12.5 mm coarse aggregate | 2.70 |
| M-sand/crushed stone sand | 2.65 |
| Water | 1.00 |
The specific gravity values are assumed for this worked example. Actual laboratory test results must be used for the final mix.
2.3 Aggregate Moisture Condition
The main calculation is based on saturated surface-dry aggregate conditions.
Actual batching requires correction for:
- Aggregate absorption
- Free surface moisture
- Stockpile condition
- Rainfall or drying
- Aggregate temperature
- Batch-plant weighing procedure
The quantities calculated in this article must not be used directly for production without moisture correction.
3. Target Mean Strength
The characteristic compressive strength of M25 concrete is:
fck = 25 N/mm²
When sufficient test data are not available, the assumed standard deviation for M25 may be taken as:
S = 4.0 N/mm²
For the grade-dependent margin method:
X = 5.5 N/mm²
The target mean strength is calculated using both expressions.
3.1 Calculation Using Standard Deviation
f′ck = fck + 1.65S
f′ck = 25 + (1.65 × 4.0)
f′ck = 31.60 N/mm²
3.2 Calculation Using Grade-Dependent Margin
f′ck = fck + X
f′ck = 25 + 5.5
f′ck = 30.50 N/mm²
The higher value is adopted:
Target mean strength = 31.60 N/mm²
The actual standard deviation should be calculated from project test results whenever sufficient production data become available.
4. Selection of Water–Cement Ratio
For moderate-exposure RCC, the reference maximum water–cement ratio is:
Maximum permitted water–cement ratio = 0.50
For this initial trial calculation:
Adopted calculation-basis water–cement ratio = 0.46
The selected value is below the maximum durability limit of 0.50.
The selected value must also satisfy:
- Target mean strength
- Durability requirements
- Required workability
- Aggregate grading
- Cement characteristics
- Admixture compatibility
- Trial-mix strength results
The value of 0.46 is an initial trial value and is not a universal water–cement ratio for every M25 concrete mix.
5. Water Content Calculation
For 20 mm angular aggregate and a reference slump of 25–50 mm, the approximate water content is:
Water content = 186 litres/m³
The required target slump is:
Target slump = 100 mm
Taking 50 mm as the reference slump, the increase is approximately 50 mm.
Using an approximate 3% increase for every 25 mm increase in slump:
Water increase = 3% × 2 = 6%
5.1 Water Before Admixture Reduction
Water = 186 × 1.06
Water = 197.16 litres/m³
Therefore:
Water before admixture reduction ≈ 197 litres/m³
5.2 Water Reduction Using Superplasticizer
For this illustrative calculation, a 30% water reduction is assumed due to the use of a compatible superplasticizer.
This 30% reduction is not a fixed code value. It must be confirmed by trial mixing using the actual cement, aggregates and admixture.
Reduced water = 197.16 × 0.70
Reduced water = 138.01 litres/m³
Adopted value:
External design water = 138 litres/m³
5.3 Water-Balance Note for Liquid Admixture
For this illustrative calculation, 138 litres/m³ is treated as the externally added design water. The liquid superplasticizer is included separately by its full mass and volume.
The water contribution of the liquid admixture is not included in the 138 litres/m³ figure because the manufacturer’s product water content has not been specified.
For an approved final mix, obtain the admixture water content from the manufacturer’s datasheet and include it in the final effective water–cement ratio and absolute-volume calculation. Use one consistent water-balance basis and do not count the same water twice.
6. Cement Content Calculation
The durability-based minimum cement content for the selected moderate-exposure RCC condition is:
Minimum cement content = 300 kg/m³
Cement required based on the maximum water–cement ratio:
Cement = Water ÷ Maximum permitted water–cement ratio
Cement = 138 ÷ 0.50
Cement = 276 kg/m³
| Check | Cement required |
|---|---|
| Maximum water–cement ratio check | 276 kg/m³ |
| Durability minimum | 300 kg/m³ |
The durability minimum governs the initial selection.
Adopted cement content = 300 kg/m³
Calculation-basis water–cement ratio:
Calculation-basis water–cement ratio = External design water ÷ Cement
Calculation-basis water–cement ratio = 138 ÷ 300
Calculation-basis water–cement ratio = 0.46
The adopted cement content must be confirmed through target-strength, workability, durability and trial-mix results.
7. Chemical Admixture Content
The superplasticizer dosage is assumed as 0.60% by mass of cement.
Admixture quantity = 300 × 0.60 ÷ 100
Admixture quantity = 1.80 kg/m³
Therefore:
Superplasticizer = 1.80 kg/m³
Volume of liquid admixture:
Volume of admixture = Mass ÷ (Specific gravity × 1000)
Volume of admixture = 1.80 ÷ (1.09 × 1000)
Volume of admixture = 0.00165 m³
The final dosage must be checked against:
- Manufacturer’s recommended dosage range
- Compatibility with OPC 53 cement
- Slump and slump-retention requirements
- Setting time
- Bleeding and segregation
- Trial-mix strength
The water contained in the liquid admixture must be checked separately against the final effective water–cement ratio. It is not included in the 138 litres/m³ external-water figure used in this illustrative calculation.
8. Coarse and Fine Aggregate Proportioning
For 20 mm nominal maximum-size aggregate and Zone II fine aggregate, the reference coarse-aggregate volume fraction at a water–cement ratio of 0.50 is approximately:
Reference coarse-aggregate fraction = 0.62
The selected calculation-basis water–cement ratio is 0.46.
Difference = 0.50 − 0.46
Difference = 0.04
Using an approximate 0.01 adjustment for every 0.05 change:
Adjustment = (0.04 ÷ 0.05) × 0.01
Adjustment = 0.008
Corrected coarse-aggregate fraction:
Coarse aggregate fraction = 0.62 + 0.008
Coarse aggregate fraction = 0.628
Fine-aggregate fraction:
Fine aggregate fraction = 1.00 − 0.628
Fine aggregate fraction = 0.372
These are initial proportioning values. The final aggregate blend must be confirmed by sieve analysis, grading, workability and trial-mix results.
9. Absolute Volume Calculation
The absolute-volume method is used for one cubic metre of concrete.
9.1 Volume of Cement
Volume of cement = Mass ÷ (Specific gravity × 1000)
Volume of cement = 300 ÷ (3.15 × 1000)
Volume of cement = 0.0952 m³
9.2 Volume of External Design Water
Volume of water = 138 ÷ (1.00 × 1000)
Volume of water = 0.1380 m³
9.3 Volume of Superplasticizer
Volume of admixture = 0.00165 m³
9.4 Volume of Entrapped Air
For normal non-air-entrained concrete with 20 mm aggregate:
Entrapped air = 1%
Volume of air = 0.010 m³
9.5 Volume Available for Aggregates
Volume of aggregates = 1 − (Volume of cement + Volume of water + Volume of admixture + Volume of air)
Volume of aggregates = 1 − (0.0952 + 0.1380 + 0.00165 + 0.010)
Volume of aggregates ≈ 0.7551 m³
9.6 Coarse Aggregate Quantity
Volume of coarse aggregate = 0.7551 × 0.628
Volume of coarse aggregate ≈ 0.4742 m³
Mass of coarse aggregate = 0.4742 × 2.70 × 1000
Mass of coarse aggregate ≈ 1,280 kg/m³
9.7 Fine Aggregate Quantity
Volume of fine aggregate = 0.7551 − 0.4742
Volume of fine aggregate ≈ 0.2809 m³
Mass of fine aggregate = 0.2809 × 2.65 × 1000
Mass of fine aggregate ≈ 744 kg/m³
10. Final Initial Trial Mix per Cubic Metre
| Material | Quantity per m³ |
|---|---|
| OPC 53 cement | 300 kg |
| Fine aggregate | 744 kg |
| Coarse aggregate | 1,280 kg |
| External design water | 138 litres |
| Superplasticizer | 1.80 kg |
| Calculation-basis water–cement ratio | Approximately 0.46 |
| Target slump | 100 mm |
| Entrapped air | Approximately 1% |
The quantities are based on assumed material properties and saturated surface-dry aggregates.
They represent an initial trial mix only and must be adjusted after testing the actual materials.

11. Approximate Coarse Aggregate Split
For an initial combined coarse-aggregate blend:
| Aggregate size | Approximate percentage | Quantity |
|---|---|---|
| 20 mm aggregate | 60% | 768 kg |
| 12.5 mm aggregate | 40% | 512 kg |
| Total coarse aggregate | 100% | 1,280 kg |
The 60:40 split is only an initial trial proportion. The final blend must be selected according to actual sieve analysis and combined grading.
12. Approximate Mass-Based Trial Proportion
Taking cement as one part:
Cement : Fine aggregate : Coarse aggregate
300 : 744 : 1280
1 : 2.48 : 4.27
This is an approximate calculated mass-based trial proportion. It is not a fixed nominal volumetric ratio such as 1:2:4.
13. Quantities for a 50-Litre Trial Batch
A 50-litre trial batch is equal to:
50 litres = 0.05 m³
| Material | Quantity for 50 litres |
|---|---|
| OPC 53 cement | 15.00 kg |
| Fine aggregate | 37.20 kg |
| Coarse aggregate | 64.00 kg |
| External design water | 6.90 litres |
| Superplasticizer | 90 g |
The plant water must be adjusted for aggregate moisture. The liquid admixture is added separately, and its water contribution must be checked in the final effective water–cement ratio and absolute-volume calculation using the manufacturer’s datasheet.
14. Moisture and Absorption Correction
The calculated quantities are based on saturated surface-dry aggregate conditions.
For this simplified illustration, assume:
- Fine aggregate free surface moisture = 3%
- Coarse aggregate free surface moisture = 1%
These values are only examples and must not be used directly for production batching.
14.1 Water Contributed by Fine Aggregate
Water = 744 × 0.03
Water = 22.32 litres
14.2 Water Contributed by Coarse Aggregate
Water = 1280 × 0.01
Water = 12.80 litres
14.3 Total Water Contributed by Aggregates
Total water = 22.32 + 12.80
Total water = 35.12 litres
14.4 Plant Water to Be Added
Plant water to be added = External design water − Water contributed by aggregates
Plant water to be added = 138 − 35.12
Plant water to be added = 102.88 litres/m³
Under the external-water basis used here, 102.88 litres is the plant water after subtracting the assumed aggregate free moisture.
The actual plant water must be calculated using measured moisture and absorption values. The water contained in the liquid admixture must be checked separately according to the selected final water-balance basis.
14.5 Wet Fine Aggregate Quantity
Wet fine aggregate = 744 × 1.03
Wet fine aggregate ≈ 766 kg
14.6 Wet Coarse Aggregate Quantity
Wet coarse aggregate = 1280 × 1.01
Wet coarse aggregate ≈ 1,293 kg
If the aggregate is below saturated surface-dry condition, additional water may be absorbed by the aggregate. The actual absorption correction must be calculated from laboratory test results.
15. Trial-Mix and Quality-Control Requirements
Before approving the mix for production, conduct laboratory and site trials using the actual materials.
Check the following:
- Slump immediately after mixing
- Slump retention where delivery time is significant
- Concrete temperature
- Bleeding and segregation
- Fresh concrete density and yield
- Admixture compatibility and setting time
- Aggregate moisture correction
- Cube compressive strength at specified ages
- Workability and finishability
- Batch-to-batch consistency
- Compliance with strength and durability requirements
- Final approval by the responsible engineer
Do not add unmeasured water at the site to correct slump. Workability adjustments must follow the approved admixture procedure and documented trial results.
Suggested Trial-Mix Record
| Trial | Cement | Water | Admixture dosage | Slump | Density | 7-day strength | 28-day strength | Remarks |
|---|---|---|---|---|---|---|---|---|
| Trial 1 | Record | Record | Record | Record | Record | Record | Record | Record |
| Trial 2 | Record | Record | Record | Record | Record | Record | Record | Record |
| Trial 3 | Record | Record | Record | Record | Record | Record | Record | Record |
The final mix should be selected only after confirming the required strength, workability, durability and production consistency.
16. Common Errors to Avoid
- Treating 300 kg/m³ as the final cement content for every M25 mix
- Using M25 without checking the actual exposure condition
- Treating 30% water reduction as a fixed code value
- Ignoring water contained in liquid admixture
- Using saturated surface-dry quantities without moisture correction
- Adding uncontrolled water at the site
- Treating 1:2.48:4.27 as a nominal volumetric ratio
- Using the same mix for pumping without a separate pump trial
- Changing M-sand to river sand without a new trial mix
- Using assumed specific gravities for final production
- Approving the mix without cube-strength verification
- Ignoring bleeding, segregation or slump retention
17. Frequently Asked Questions
Is this the final M25 concrete mix?
No. It is an initial trial mix based on stated assumptions. The final production mix requires laboratory and site verification using actual materials.
Why is 300 kg/m³ cement adopted?
For moderate-exposure RCC, 300 kg/m³ is the adopted durability minimum in this example. The water-to-maximum water–cement ratio check requires 276 kg/m³, but the durability minimum of 300 kg/m³ governs the preliminary selection.
Is M25 the minimum RCC grade for every exposure condition?
No. The minimum RCC grade depends on exposure. M25 is associated with the selected moderate-exposure condition in this example. Mild, severe and more aggressive exposure conditions require separate checks.
Can this M25 mix be used for plain concrete?
Not automatically. Plain concrete may have different durability and cement-content requirements. A separate mix design should be prepared for the actual application and exposure condition.
Can 300 kg/m³ cement achieve a 100 mm slump?
It may achieve the required slump when a compatible superplasticizer is used. The assumed water reduction and admixture dosage must be confirmed through trial mixing.
Is the ratio 1:2.48:4.27 a nominal mix ratio?
No. It is an approximate calculated mass-based trial proportion. It is not a traditional nominal volumetric mix ratio.
Can this mix be used for pumped concrete?
Not automatically. Pumped concrete requires separate checks for aggregate grading, paste volume, pumpability, slump retention and segregation resistance.
Can river sand replace M-sand directly?
No direct substitution should be made. A change in fine aggregate requires new checks for grading, moisture, absorption, workability and strength.
Can the cement quantity be reduced below 300 kg/m³?
It should not be reduced for the selected moderate-exposure RCC condition without checking the applicable durability requirement, project specification, target strength and approval requirements.
Is the 30% water reduction guaranteed?
No. It is only an illustrative assumption. The actual reduction depends on cement chemistry, aggregate grading, admixture type, dosage, temperature and mixing conditions.
18. Related Resources
- Concrete Mix Design Hub
- Concrete Mix Design Calculator as per IS 10262:2019
- M10 Concrete Mix Design as per IS 10262:2019
- M15 Concrete Mix Design as per IS 10262:2019
- M20 Concrete Mix Design with OPC Cement
- M55 Concrete Mix Design
Technical Basis and Applicable Standards
This educational example is based on the general principles of:
- IS 10262:2019 — Concrete Mix Proportioning: Guidelines
- IS 456:2000 — Plain and Reinforced Concrete: Code of Practice, including applicable amendments
- IS 383:2016 — Coarse and Fine Aggregate for Concrete: Specification
- IS 9103 — Concrete Admixtures: Specification
Always verify the latest applicable editions, amendments, project specifications and laboratory requirements before use.
Conclusion
The preliminary M25 concrete trial mix per cubic metre is:
- OPC 53 cement: 300 kg
- Fine aggregate: approximately 744 kg
- Coarse aggregate: approximately 1,280 kg
- External design water: 138 litres
- Superplasticizer: 1.80 kg
- Calculation-basis water–cement ratio: approximately 0.46
- Target slump: 100 mm
- Approximate mass-based trial proportion: 1:2.48:4.27
These quantities are valid only for the stated materials, grading, specific gravities, moisture condition, admixture dosage and design assumptions.
Final approval requires trial-mix testing, cube-strength verification, durability checks and confirmation by the responsible project engineer.
About T Square Civil Engineering
T Square Civil Engineering provides practical civil-engineering explanations, concrete technology guidance, construction calculations and site-oriented learning resources.
The content connects engineering theory with construction practice, testing, quality control and field application—from Theory to Construction Practice.
Disclaimer
The information on this website is provided for educational purposes only.
It does not replace project-specific engineering design, professional advice, approved drawings or construction specifications. Examples, calculations and suggested procedures should not be adopted directly for construction without appropriate verification. Always check the latest applicable standards and amendments, local requirements, project specifications, material-test results and site conditions.
Final design, testing, acceptance and construction decisions should be made by qualified professionals and the responsible project authorities.
T Square Civil Engineering is an independent educational platform and is not affiliated with the Bureau of Indian Standards, any government authority, cement manufacturer or admixture manufacturer mentioned on this page.
