M35 concrete is a design-mix grade with a characteristic compressive strength of 35 N/mm² at 28 days. Unlike nominal concrete, the quantities of cement, water, fine aggregate, coarse aggregate and admixture must be established from the actual material properties, required workability, exposure condition and laboratory trial results.
This article presents an educational preliminary mix-design example for M35 concrete using OPC 53 cement, 20 mm crushed coarse aggregate, Zone II fine aggregate and a superplasticizer for approximately 100 mm slump.
This example is not a universal site mix. The final mix must be approved after laboratory trials, slump testing, cube testing, moisture correction and confirmation of the project specifications.
Page Contents
Important basis of this example
This page intentionally presents an OPC-based M35 mix. It does not use GGBS. A separate GGBS mix should be designed using cementitious-material calculations and GGBS-specific trial results.
The following assumptions are used:
| Parameter | Assumed value |
|---|---|
| Concrete grade | M35 |
| Characteristic compressive strength at 28 days | 35 N/mm² |
| Cement | OPC 53 grade |
| Maximum nominal aggregate size | 20 mm |
| Fine aggregate | Zone II |
| Coarse aggregate | Crushed angular aggregate |
| Exposure condition | Moderate |
| Required slump | Approximately 100 mm |
| Entrapped air | 1% |
| Chemical admixture | Superplasticizer |
| Initial water-reduction assumption | 20% for this worked example |
| Adopted water–cement ratio | 0.45 |
| Aggregate condition for calculations | Saturated surface dry |
| Degree of site control | Good |
Applicable Indian Standards
The following standards should be checked in their latest applicable editions and amendments:
- IS 10262:2019 — Concrete Mix Proportioning — Guidelines
- IS 456:2000 — Plain and Reinforced Concrete — Code of Practice
- IS 383 — Coarse and Fine Aggregate for Concrete
- IS 269 — Ordinary Portland Cement
- IS 9103 — Concrete Admixtures
- IS 1199 — Methods of Sampling and Analysis of Concrete
- IS 516 — Methods of Tests for Strength of Concrete
Why a design mix is required for M35 concrete
M35 is a standard design-mix grade. Its proportions should not be selected only by using a fixed cement:sand ratio.
The final proportions depend on:
- target mean strength;
- cement strength and specific gravity;
- aggregate grading and specific gravity;
- fine-aggregate grading zone;
- water–cement ratio;
- required slump;
- admixture performance;
- exposure condition;
- aggregate moisture and absorption;
- mixing and placing method; and
- trial-mix results.
A mix that works with one source of cement or aggregate may not produce the same strength and workability with another source.
Design data and material properties
The following material properties are assumed for this educational calculation. Actual laboratory test results must be used for a project mix.
| Material | Assumed property |
|---|---|
| Specific gravity of OPC | 3.15 |
| Specific gravity of fine aggregate | 2.65 |
| Specific gravity of coarse aggregate | 2.70 |
| Specific gravity of superplasticizer | 1.10 |
| Fine-aggregate grading | Zone II |
| Maximum nominal size of coarse aggregate | 20 mm |
| Entrapped air | 1% by volume |
The cement and aggregates should be tested before finalising the mix. The relevant test results should include specific gravity, grading, moisture content, water absorption, bulk density and other project-specified properties.
Step 1: Calculate the target mean strength
The characteristic compressive strength of M35 concrete is:
fck = 35 N/mm²
When sufficient site test data is not available, the assumed standard deviation for M30 to M35 concrete is taken as:
s = 5 N/mm²
As per the mix-design approach, the target mean strength is calculated using:
f′ck = fck + 1.65s
Therefore:
f′ck = 35 + (1.65 × 5)
f′ck = 35 + 8.25
f′ck = 43.25 N/mm²
The alternative expression is:
f′ck = fck + X
For M35, the assumed value of X is 6.5 N/mm².
f′ck = 35 + 6.5
f′ck = 41.5 N/mm²
The higher value is selected.
Therefore, the target mean strength for this preliminary calculation is:
Target mean strength = 43.25 N/mm²
If sufficient recent site data is available, the actual standard deviation from the approved production records should be used instead of the assumed value.
Step 2: Select the water–cement ratio
For this worked example, the water–cement ratio is initially selected as:
Adopted water–cement ratio = 0.45
This value must satisfy both strength and durability requirements.
For moderate exposure, the maximum water–cement ratio for reinforced concrete is generally taken as 0.50, subject to the applicable project specification and latest code requirements.
Check:
Adopted water–cement ratio = 0.45
Maximum permitted value assumed for moderate exposure = 0.50
Therefore:
0.45 < 0.50
The selected ratio satisfies the assumed durability limit. However, the final ratio must be confirmed through trial mixes and strength testing.
Step 3: Calculate the water content
For 20 mm nominal maximum aggregate size and approximately 50 mm slump, the base water content is taken as:
Water content = 186 kg/m³
The required slump for this example is approximately 100 mm.
The increase from 50 mm to 100 mm is:
100 − 50 = 50 mm
This represents two increments of 25 mm.
The water-content increase is taken as 3% for each 25 mm increase:
Increase = 2 × 3% = 6%
Water content before using superplasticizer:
Water = 186 × 1.06
Water = 197.16 kg/m³
A superplasticizer is used in this example. For preliminary calculation, a 20% water reduction is assumed. This is only an assumed trial value and is not a universal value for all admixtures.
Water after assumed admixture reduction:
Water = 197.16 × 0.80
Water = 157.73 kg/m³
Adopt:
Free water = 158 kg/m³
The actual reduction must be established from the admixture compatibility and trial-mix results. Water should not be reduced only because an admixture is added.
Step 4: Calculate cement content
The cement content is calculated from the free water and adopted water–cement ratio:
Cement content = Water / Water–cement ratio
Cement content = 157.73 / 0.45
Cement content = 350.5 kg/m³
Adopt:
Cement content = 351 kg/m³
Durability check
For the assumed moderate exposure condition:
- Minimum cement content assumed = 300 kg/m³
- Calculated cement content = 351 kg/m³
Therefore:
351 kg/m³ > 300 kg/m³
The calculated cement content satisfies the assumed minimum cement-content requirement.
The calculated cement content is also below 450 kg/m³. If a cement content greater than the applicable maximum is proposed, special consideration and approval are required.
Important clarification about minimum cement
The minimum cement content is a durability requirement. It is not automatically the final cement content for every mix.
In this example, 351 kg/m³ is adopted because it is obtained from the calculated water content and selected water–cement ratio. The value is also higher than the assumed minimum requirement of 300 kg/m³.
The value 380 kg/m³ should not be described as the universal minimum cement content for M35 concrete under moderate exposure. It could be adopted only when justified by the project design, workability, durability, strength, material properties or trial results.
Step 5: Select superplasticizer quantity
For this preliminary calculation, the superplasticizer dosage is assumed as 1% by mass of cement.
Superplasticizer dosage:
= 1% × 351
= 3.51 kg/m³
Adopt:
Superplasticizer = 3.5 kg/m³
The actual dosage must be within the manufacturer’s recommended range and must be confirmed by trial. The admixture should conform to the applicable requirements of IS 9103.
A superplasticizer can reduce the water required for a given workability. It does not automatically permit a reduction in cement content. Any reduction in cement must still satisfy:
- target strength;
- water–cement ratio;
- minimum cement or cementitious-material requirement;
- durability;
- workability;
- finishing and placing requirements; and
- trial-mix performance.
Step 6: Calculate the volume of total aggregate
The absolute-volume method is used.
Volume of cement
Volume of cement:
= Mass of cement / (Specific gravity × 1000)
= 351 / (3.15 × 1000)
= 0.1114 m³
Volume of water
Volume of water:
= 158 / 1000
= 0.1580 m³
Volume of superplasticizer
Volume of admixture:
= 3.5 / (1.10 × 1000)
= 0.0032 m³
Volume of entrapped air
For 20 mm nominal maximum aggregate size:
Entrapped air = 1%
Volume of air:
= 1/100
= 0.0100 m³
Volume of all aggregates
Volume of all aggregates:
= 1 − [volume of cement + volume of water + volume of admixture + volume of air]
= 1 − [0.1114 + 0.1580 + 0.0032 + 0.0100]
= 0.7174 m³
Therefore:
Total aggregate volume = 0.7174 m³
Step 7: Calculate coarse-aggregate and fine-aggregate proportions
For 20 mm aggregate, Zone II fine aggregate and a water–cement ratio of 0.50, the volume of coarse aggregate per unit volume of total aggregate is taken as 0.62.
The adopted water–cement ratio is 0.45, which is 0.05 lower than 0.50.
The coarse-aggregate volume is increased by 0.01:
Corrected coarse-aggregate fraction:
= 0.62 + 0.01
= 0.63
Fine-aggregate fraction:
= 1 − 0.63
= 0.37
These values are preliminary. The aggregate proportions may require adjustment for crushed sand, manufactured sand, aggregate shape, grading, pumpability and trial workability.
Step 8: Calculate coarse aggregate quantity
Volume of coarse aggregate:
= Total aggregate volume × Coarse-aggregate fraction
= 0.7174 × 0.63
= 0.4520 m³ approximately
Mass of coarse aggregate:
= 0.4520 × 2.70 × 1000
= 1,220 kg/m³ approximately
Therefore:
Coarse aggregate = 1,220 kg/m³
Step 9: Calculate fine aggregate quantity
Volume of fine aggregate:
= Total aggregate volume × Fine-aggregate fraction
= 0.7174 × 0.37
= 0.2654 m³ approximately
Mass of fine aggregate:
= 0.2654 × 2.65 × 1000
= 703 kg/m³ approximately
Therefore:
Fine aggregate = 703 kg/m³
Preliminary M35 mix proportions for 1 m³
The preliminary mix proportions on an SSD aggregate basis are:
| Material | Quantity per m³ |
|---|---|
| OPC 53 cement | 351 kg |
| Free water | 158 litres |
| Fine aggregate, Zone II | 703 kg |
| Coarse aggregate, 20 mm | 1,220 kg |
| Superplasticizer | 3.5 kg |
| Water–cement ratio | 0.45 |
| Target slump | Approximately 100 mm |
The approximate mass ratio is:
Cement : Fine aggregate : Coarse aggregate
1 : 2.00 : 3.48
This ratio is shown only for understanding. Concrete should be batched by mass using the approved mix proportions, not by using a fixed volume ratio.

Absolute-volume verification
The calculated volumes are approximately:
| Component | Volume |
|---|---|
| Cement | 0.1114 m³ |
| Water | 0.1580 m³ |
| Superplasticizer | 0.0032 m³ |
| Entrapped air | 0.0100 m³ |
| Fine aggregate | 0.2654 m³ |
| Coarse aggregate | 0.4520 m³ |
| Total | Approximately 1.0000 m³ |
This confirms the absolute-volume balance for the assumed material properties.
Quantities for a 50-litre trial batch
For a 50-litre trial batch:
50 litres = 0.05 m³
| Material | Quantity for 0.05 m³ |
|---|---|
| Cement | 17.6 kg |
| Free water | 7.9 litres |
| Fine aggregate | 35.2 kg |
| Coarse aggregate | 61.0 kg |
| Superplasticizer | 0.18 kg approximately |
These are theoretical SSD-basis quantities. The actual trial batch must be corrected for aggregate moisture, absorption, equipment capacity and measured yield.
Moisture correction example
The mix quantities above are based on saturated surface dry aggregate conditions. Actual site aggregates are rarely in SSD condition.
Assume the following field readings:
| Aggregate | Moisture | Absorption |
|---|---|---|
| Fine aggregate | 4.0% | 1.0% |
| Coarse aggregate | 1.0% | 0.5% |
Fine aggregate correction
SSD fine aggregate quantity = 703 kg
Approximate wet batching quantity:
= 703 × 1.04 / 1.01
= 724 kg approximately
Free water contributed by fine aggregate:
= approximately 21 kg
Coarse aggregate correction
SSD coarse aggregate quantity = 1,220 kg
Approximate wet batching quantity:
= 1,220 × 1.01 / 1.005
= 1,226 kg approximately
Free water contributed by coarse aggregate:
= approximately 6 kg
Corrected water to be added
Total free water contributed by aggregates:
= 21 + 6
= 27 litres approximately
Water to be added at the mixer:
= Required free water − free water contributed by aggregates
= 158 − 27
= 131 litres approximately
The actual correction must be based on the moisture and absorption test results taken close to batching time.
Trial-mix procedure
The above quantities are a preliminary starting mix. The final mix should be established through laboratory and field trials.
Trial 1
Prepare the calculated mix and check:
- slump;
- visual cohesion;
- segregation;
- bleeding;
- concrete temperature;
- density and yield; and
- ease of mixing and placing.
Trial 2
If the slump or cohesion is not satisfactory, adjust the superplasticizer dosage within the approved range. Do not add uncontrolled water.
Record the actual:
- batch quantities;
- water added;
- admixture dosage;
- slump;
- temperature;
- density;
- air content, where required; and
- cube identification numbers.
Trial 3
Prepare additional trials around the selected water–cement ratio, subject to the durability limit and project specification. Cast concrete cubes and compare the strength results with the target mean strength.
The final mix should be selected only after confirming strength, workability, durability-related requirements and production consistency.
Cube casting and strength testing
For each trial, prepare concrete specimens according to the applicable testing procedure and project quality-control plan.
Record:
- date and time of casting;
- mix identification;
- cement and aggregate sources;
- batch quantities;
- slump;
- concrete temperature;
- cube dimensions;
- curing conditions;
- test age; and
- compressive-strength results.
Cubes are commonly tested at 7 days and 28 days for mix-development and quality-control purposes. The number of cubes and test frequency should follow the approved project quality plan and applicable standards.
The 28-day result should be assessed against the required characteristic strength, target mean strength and the applicable acceptance criteria. One isolated cube result should not be interpreted without considering the complete test set and project acceptance requirements.
Practical site and quality-control points
- Use weigh batching for cement, aggregates, water and admixture.
- Check aggregate moisture before production.
- Do not add water at site without approval and recalculation.
- Verify the admixture dosage using a calibrated dispensing system.
- Check the actual slump at the point specified by the project procedure.
- Do not use the calculated mix without trial approval.
- Keep cement and admixture from incompatible or unapproved sources out of the mix.
- Confirm the fine-aggregate grading before changing the aggregate proportion.
- Recheck the mix when the aggregate source, cement source or admixture changes.
- Ensure proper compaction and curing.
- Maintain batch records and cube-test records.
- If pumping is required, conduct a separate pumpability trial because aggregate proportion and paste volume may require adjustment.
Common mistakes in M35 mix design
Treating minimum cement as the final cement quantity
The minimum cement requirement is a durability control. It is not automatically the final quantity. The final quantity must also satisfy strength, workability and absolute-volume calculations.
Using 380 kg/m³ as a universal minimum
A value of 380 kg/m³ is not automatically the minimum cement requirement for every M35 mix. For the assumed moderate exposure in this example, 351 kg/m³ satisfies the assumed 300 kg/m³ minimum and is obtained from the selected water and water–cement ratio.
Reducing cement only because a superplasticizer is added
A superplasticizer primarily reduces water demand for a required workability. Cement reduction is possible only after checking the final water–cement ratio, strength, durability, minimum content and trial results.
Ignoring aggregate moisture
Using SSD quantities directly for wet or dry aggregates changes both the batch mass and effective water–cement ratio. Moisture correction is essential.
Using a fixed ratio for every M35 concrete
M35 does not have one universal 1:2:4 or 1:1.5:3 ratio. The proportions depend on actual materials and project requirements.
Adding site water to improve slump
Uncontrolled water addition increases the water–cement ratio and can reduce strength and durability. Adjust the approved admixture dosage or redesign the mix after proper trial verification.
Frequently asked questions
Is M35 concrete a nominal mix?
No. M35 should normally be produced as a design mix based on IS 10262:2019 and the approved project requirements.
What is the target mean strength for M35 concrete?
Using an assumed standard deviation of 5 N/mm²:
f′ck = 35 + 1.65 × 5
Therefore, the target mean strength is 43.25 N/mm² for this preliminary example.
Is 300 kg/m³ cement enough for this M35 mix?
For the assumed moderate exposure, 300 kg/m³ is treated as the minimum durability requirement. It is not automatically sufficient to achieve the required strength and workability. In this worked example, the calculated cement content is 351 kg/m³.
Can 250 kg/m³ cement be used for this M35 mix?
Not for the assumed moderate-exposure reinforced-concrete example because it is below the assumed minimum cement requirement and would not satisfy the present water–cement calculation. A different material system would require a separate approved design and verification.
Can GGBS be used in M35 concrete?
Yes, but the mix must be redesigned as a cementitious-material mix. GGBS replacement, specific gravity, water–cementitious-material ratio, setting characteristics and strength development must be confirmed through trials. The OPC-only example on this page should not be used as a GGBS mix.
Does superplasticizer reduce cement content?
It can reduce water demand and may allow a lower cement content in a properly redesigned mix. However, cement cannot be reduced automatically. Strength, durability, minimum content, workability and trial results must remain satisfactory.
Is the 100 mm slump fixed for every M35 concrete?
No. The slump depends on placing method, reinforcement congestion, transport time, pumping requirements and project specifications. The 100 mm value used here is only the design assumption for this worked example.
Can this mix be used directly at site?
No. It is an educational preliminary calculation. The mix must be verified using actual materials, moisture corrections, trial batches, slump testing, cube testing and approval by the responsible project authority.
Conclusion
The preliminary M35 mix calculated in this example is:
| Material | Preliminary quantity per m³ |
|---|---|
| OPC 53 cement | 351 kg |
| Free water | 158 litres |
| Fine aggregate | 703 kg |
| Coarse aggregate | 1,220 kg |
| Superplasticizer | 3.5 kg |
| Water–cement ratio | 0.45 |
The calculated cement content is higher than the assumed moderate-exposure minimum of 300 kg/m³ and lower than 450 kg/m³. However, these values are not a substitute for an approved project mix design.
The final mix must be confirmed through laboratory trials, moisture correction, workability testing, cube testing and production-control checks.
Related concrete mix-design resources
- Concrete Mix Design Hub
- Concrete Mix Design Calculator as per IS 10262:2019
- Target Mean Strength of Concrete
- Water Content Calculation in Concrete Mix Design
- Superplasticizer in Concrete Mix Design
- Moisture Correction in Concrete Mix Design
- Concrete Trial Mix Procedure
- Mix Design of M30 Grade Concrete
- Mix Design of M40 Grade Concrete
About T Square Civil Engineering
T Square Civil Engineering is an independent educational platform providing civil engineering explanations, construction calculations, laboratory-test procedures, concrete technology guidance and practical site-learning resources.
The content is prepared for students, technicians, site engineers and construction professionals who want to connect engineering theory with construction practice.
Disclaimer
The information on this website is provided for educational purposes only.
It does not replace project-specific engineering design, professional advice, approved drawings or construction specifications. Examples, calculations and suggested procedures should not be adopted directly for construction without appropriate verification. Always check the latest applicable standards and amendments, local requirements, project specifications, material-test results and site conditions.
Final design, testing, acceptance and construction decisions should be made by qualified professionals and the responsible project authorities.
T Square Civil Engineering is an independent educational platform and is not affiliated with the Bureau of Indian Standards, any government authority, cement manufacturer or admixture manufacturer mentioned on this page.
